Dura Flo PC Dripline

Dura Flo™ PC Pressure Compensating Dripline

Count on a steady flow of water delivered along the entire line with the Dura Flo™ Dripline. This tubing features pressure-compensating (PC) emitters evenly spaced apart and have a constant flow rate should the water pressure change.
Alt Text Goes Here

Key Features

  • Emitters have a turbulent flow design which flushes out sediments that can lead to clogging
  • The pressure-compensating dripline delivers a steady, uniform amount of water even if there are changes in pressure, elevation, or length of dripline used
  • Poly tubing is constructed using a layering method for durability: the outer and inner layers are made of 100% virgin content; the middle layer is composed of recycled content
  • Roll is shrink-wrapped for easy handling and to ensure roll stays together as product is dispensed

Applications

  • Delivers a steady flow of water along the entire line even if the pressure changes; self-cleaning emitters are spaced evenly apart

  • Ideal for watering closely spaced plants, hedges, vegetable gardens, planter boxes, and new plantings of ground cover; its flexibility also works as a watering ring for large pots and containers, and makes loops around large trees

  • As part of a complete drip irrigation system, the dripline delivers water along the entire line, and each of the pressure-compensating emitters distributes water steadily even if the pressure changes

Installation & Maintenance

  • Use tubing adapter to connect to water source

  • Use insert fittings, Smart Loc™ multidiameter fittings, or compression fittings to connect sections of dripline together, make bends, or add a tee intersection

  • Periodically check for leaks or damage and replace or repair as needed; recommended operating pressure is up to 50 PSI; for areas with freezing temperatures, winterize by using an air compressor to evacuate lines with air to remove water

Materials & Sustainability

  • Tubing made of polyethylene

  • Emitters made of polyethylene and silicone

  • Made of domestic and imported materials

  • Drip irrigation can reduce water usage by up to 70% compared to conventional sprinkler irrigation when used properly; for most drip irrigation products, water is applied precisely and at the rate the soil can accept it to prevent runoff and erosion

Product Models

Part Number
Description
SFPC-BR-6212-02516mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 250 ft.
SFPC-BR-6212-0516mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BL-6412-0116mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Black Polyethylene, 100 ft.
SFPC-BR-6412-0116mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 100 ft.
SFPC-BR-6412-02516mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 250 ft.
SFPC-BR-6412-0516mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BR-6418-0116mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 100 ft.
SFPC-BR-6418-02516mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 250 ft.
SFPC-BR-6418-0516mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BL-6418-0516mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 18 in. Spacing, Black Polyethylene, 500 ft.

Part Number
Description
SFPC-BR-17212-01S17mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 100 ft.
SFPC-BR-17212-025S17mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 250 ft.
SFPC-BR-17212-05S17mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BR-17218-01S17mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 100 ft.
SFPC-BR-17218-025S17mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 250 ft.
SFPC-BR-17218-05S17mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BR-17412-025S17mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 250 ft.
SFPC-BR-17412-05S17mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BR-17412-1017mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 1,000 ft.
SFPC-PS-17412-05S17mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown with Purple Stripe Polyethylene, 500 ft.
SFPC-RC-17412-05S17mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Purple Polyethylene, 500 ft.

Part Number
Description
SFPC-BL-7212-0118mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Black Polyethylene, 100 ft.
SFPC-BL-7212-0518mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Black Polyethylene, 500 ft.
SFPC-BR-7212-0118mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 100 ft.
SFPC-BR-7218-0518mm Dura Flo™ Dripline, 0.5 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BL-7412-0118mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Black Polyethylene, 100 ft.
SFPC-BL-7412-0518mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Black Polyethylene, 500 ft.
SFPC-BR-7412-0518mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 12 in. Spacing, Brown Polyethylene, 500 ft.
SFPC-BL-7418-0518mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 18 in. Spacing, Black Polyethylene, 500 ft.
SFPC-BR-7418-0518mm Dura Flo™ Dripline, 1.0 GPH Pressure Compensating Emitters, 18 in. Spacing, Brown Polyethylene, 500 ft.
