StormChamber® Stormwater Chamber, 18 in. High, Start Unit, Orange

SKU:

SC-1820-S-O

NDS StormChamber Start Chamber used to collect, retain, and discharge storm water from residental and commerical sites (NDS SC-1820-S-0)

Capture large volumes of stormwater runoff with a smaller footprint than traditional underground systems using the NDS StormChamber® system. The arch-shaped, modular stormwater chambers can be laid out in unique configurations to fit job site requirements, and stacked to increase storage capacity while maintaining usable space above ground. This 18 in. high drainage chamber features minimum installed storage of 48 cubic feet and internal chamber volume of 24 cubic feet. The start unit is the first chamber placed in a row that can include one or more middle units and an end unit. To increase storage, additional rows can be interconnected with pipe from side portals. StormChamber units are made of thermoformed high-density weight polyethylene, engineered to withstand extreme environments, exceeds the AASHTO H-20 design load, and allow for deeper cover than other systems. Use included SedimenTrap™ devices to capture sediments and help extend the lifespan of the system.

Where to Buy Find a Contractor

Applications

Detains, infiltrates, and conveys stormwater runoff; modular system maximizes storage volume with a smaller footprint than traditional concrete and stone systems; easy to maintain
Works in commercial, industrial, municipal, and residential settings to manage stormwater runoff; ideal for installing underneath parking lots, playing fields, and landscapes
As part of a complete stormwater management system, the StormChamber® system works with a capture device or drainage inlet to detain, infiltrate, and convey collected stormwater

Features

Holds significant volume compared to other same size stormwater chambers on the market
Designed for strength due to thermoformed high-density weight polyethylene (HMWPE) material; withstands extreme environments, and exceeds the AASHTO H-20 design load
Simple install; internal crossover eliminates expensive header pipe manifold system; modular chambers overlap to form rows; side portal feed connects rows, provides greater flexibility and hydraulic design
