Applications
- Channel drains and trench drains capture and convey excess water to prevent mildew growth, concrete staining, and costly structural damage
- 12 in. Pro Series Channel Drain system collects heavy flows from hardscape surfaces such as driveways, concrete and paver patios, courtyards, walkways, and sports facilities, and directs the water to drain pipe for proper release downstream
- Works with 12 in. Pro Series Channel Drain components
Features
- The 12 in. Pro Series Channel Drain, Deep Profile, is 10-1/2 in. deep and features a modular design with interlocking joints for a secure channel-to-channel connection—no couplings required, can be cut to size as short as 4 in. long for smaller sections
- Thick channel walls and extended side ribs provide increased strength and durability
- N/A
Literature & Resources
Videos
Submit Your Design
NDS DesignWorx® Team is there to help with preparation of submittal drawings and specs. Call us at 888-825-4716 or click below.
Request a Quote
Need to submit a bid package? Let NDS Project Specialists eliminate the guesswork and accurately quote your drainage project for you.
