5 in. Pro Series™ Channel Bottom Outlet/Side Outlet, Shallow Profile, Fits 3 in. Drain Fittings, 1-1/2 in. Drain Pipe

SKU:

822

NDS 5 in. Pro Series Channel Drain, Bottom Outlet (NDS 822) includes an additional side outlet

NDS 5 in. Pro Series Channel Drain, Bottom Outlet (NDS 822) includes an additional side outlet

Add both a bottom and side outlet along the channel run with one component: the 5 in. Pro Series™ Channel Bottom Outlet/Side Outlet. Works with the 5 in. Shallow Profile Channel to drain moderate flows from driveways, patios, courtyards, walkways, and sports facilities. Bottom outlet connects to 3 in. sewer and drain fittings and side outlet connects to 1-1/2 in. Sch. 40 pipe. Made of polyvinyl chloride, it can be solvent-welded with PVC glue for a water-tight connection.

Where to Buy Find a Contractor

Applications

Connects to 5 in. Pro Series Channel Drain and outlets from bottom and side
Use with the 5 in. Pro Series Channel Drain system to collect moderate flows from driveways, concrete & paver patios, courtyards, walkways, and sports facilities, and direct the water to drain pipes for proper release downstream
Works with 5 in. Pro Series Channel Drain system, Shallow Profile

Features

Features a bottom outlet and side outlet in one component
Attaches to 5 in. Pro Series Channel Drain Shallow Profile
N/A
