Mini™ Channel Drain 90° Elbow and Grate, Sand Plastic

SKU:

5383

Alternate view of the NDS Sand Mini Channel™ Drain 90° Elbow and Grate (NDS 5383)

Side view of the NDS Sand Mini Channel™ Drain 90° Elbow and Grate (NDS 5383)

Uninstalled NDS Sand Mini Channel™ Drain 90° Elbow and Grate (NDS 5383)

Installation of couplers on either end of the NDS Sand Mini Channel™ Drain 90° Elbow and Grate (NDS 5383)

Fully installed NDS Sand Mini Channel™ Drain 90° Elbow and Grate (NDS 5383) with couplers and channel drains with grates

Closeup of the top of the opening showing the grate design of the NDS Sand Mini Channel™ Drain 90° Elbow and Grate (NDS 5383)

Create a 90° bend in your custom Mini™ Channel drainage system with the Mini Channel Drain 90° Elbow and Grate. No need to saw a straight channel drain and grate and miter together to make the angled turn. Channel is made of polyvinyl chloride and can be solvent-welded with PVC glue for a water-tight connection; grate is made of polypropylene treated with UV inhibitors. The Mini Channel Drain, part of the NDS Profile Series™ Channel, is ideal for light flows of water from pool areas, concrete and paver patios, tennis courts, walkways, and driveways. Channel drains, also called trench drains, are long, narrow drains used for surface drainage of hardscapes. As part of a complete drainage system, channel drains collect and convey water to drain pipes, which carry the water downstream to discharge with a pop-up emitter, or to percolate into the ground with a dry well or infiltration trench. NDS channel and trench drains are designed for durability, drainage, and performance, and are a proven alternative to traditional concrete drains.

Where to Buy Find a Contractor

Applications

Add a 90° turn in your Mini Channel drainage system; eliminate the need to saw a straight channel drain and grate to miter an angled bend
The Mini Channel Drain system collects light flows of water from pool & spa areas, concrete & paver patios, tennis courts, walkways, and driveways, and directs it to drain pipes for proper release downstream
Use with the Mini Channel Drain, part of the NDS Profile Channel series

Features

Mini Channel Drain elbow and grate have a 90° bend to make turns to left or right to customize layout
Mini Channel™ Drain 90° elbows and grates are available in a variety of colors
