Spee-D® Channel Drain Bottom Outlet Assembly, 4-3/4 in. X 7 in. with Channel and Prefastened Gray Plastic Grate

SKU:

2351

Spee-D® Channel Drain Bottom Outlet Assembly works with the Spee-D Channel Drain System and connects to drainage pipe in the bottom of the drain (NDS 2351*, NDS 2351)

See the grate design and the bottom pipe connection of the Spee-D® Channel Drain Bottom Outlet Assembly which works with the Spee-D Channel Drain System and connects to drainage pipe in the bottom of the drain (NDS 2351*, NDS 2351)

Bottom view of the Spee-D® Channel Drain Bottom Outlet Assembly (NDS 2351*, NDS 2351) shows fitting connection point to connect to 3 inch or 4 inch drain pipe

Side view of the Spee-D® Channel Drain Bottom Outlet Assembly showing the connection with the Spee-D Channel Drain System and the inside drain that connects to drainage pipe in the bottom of the drain (NDS 2351*, NDS 2351)

Side view of the Spee-D® Channel Drain Bottom Outlet Assembly showing the length of the drain accessory for the Spee-D Channel Drain System and the outside of the bottom outlet (NDS 2351*, NDS 2351)

The Spee-D® Channel Drain Bottom Outlet Assembly can attach to any Spee-D® Channel Drain on either end using the Spee-D® Channel Drain Coupling (NDS 2351, NDS 248)

The Spee-D® Channel Drain Bottom Outlet Assembly can attach to any Spee-D® Channel Drain on either end (NDS 2351)

Closeup view of one end of the Spee-D® Channel Drain Bottom Outlet Assembly (NDS 2351*, NDS 2351)

Top down inside view of the grate inside the Spee-D® Channel Drain Bottom Outlet Assembly which connects to drainage pie in the bottom of the drain (NDS 2351*, NDS 2351)

Closeup view of the 3 inch and 4 inch pipe connection end on the bottom of the Spee-D® Channel Drain Bottom Outlet Assembly (NDS 2351*, NDS 2351)

Capture and convey stormwater to drain pipe while blocking leaves and debris with the all-in-one Spee-D® Channel Drain Bottom Outlet Assembly. Installation time is cut down using the 7 in. channel drain with a prefastened channel drain grate. Bottom outlet, with built-in strainer, connects to 3 in. & 4 in. sewer and drain fittings. The Spee-D Channel Drain Bottom Outlet Assembly comes with a channel drain made of polyvinyl chloride (PVC) and channel drain grate made of high-density polyethylene (HDPE), treated with UV inhibitors. Spee-D Channels are part of the NDS Profile Channel series, and ideal for capturing moderate flows from driveways, concrete & paver patios, pool areas, courtyards, and walkways.

Where to Buy Find a Contractor

Applications

Use the Spee-D Channel Drain Bottom Outlet Assembly anywhere along the channel run to outlet water to drain pipe; channel drains and trench drains capture and convey excess water to prevent mildew growth, concrete staining, and costly structural damage
Spee-D Channel Drain system collects moderate water flows from driveways, concrete & paver patios, pool areas, courtyards, and walkways, and directs it to drain pipes for proper release downstream
Works with Spee-D Channel Drain system; part of the NDS Profile Channel series

Features

Spee-D Channel with fabricated grate and bottom outlet measures 4 in. wide and 7 in. long; channel comes preassembled with removable grate
Patented flying buttress design provides load-bearing support from both sides as well as underneath the channel
Bottom flanges provide an anchoring lip for straight installation and prevents floating
