BG-FILCOTEN® 200 Trench Drain Grate, 8.74 in. Wide X 19.69 in. Long, Decorative Ville Slot Design, NDS Class E Load, Ductile Iron

SKU:

17020180

Give the trench drain system an elegant look with the Ville slot design trench drain grate. This decorative grate features an intricate design. Water drains through but leaves and debris are blocked. The drain cover features an open surface area of 45.9 sq. in. per meter and 140.6 GPM flow rate. Rated for NDS Class E loads when properly installed. ADA compliant and heel-proof drainage grate. Use two half-meter (19.69 in.) grates to cover one BG-FILCOTEN 200 8 in. trench drain. Iron grates are painted black to inhibit rust. Over time, it will form a protective iron-oxide patina.

Where to Buy Find a Contractor

Applications

Prevents leaves and debris from entering the drainage system
Ideal for factories, warehouses, garages, railway stations, municipal areas, and areas with similar surfaces
As part of a complete drainage system, the BG-FILCOTEN® trench drain grate works with the channel drain to capture stormwater runoff and convey it to drain pipe for proper release downstream

Features

Grate is 8.74 in. wide and 19.69 in. long, works with BG-FILCOTEN pro V 200 channels
Rated for NDS Class E loads, handles up to 134,800 lbs.
Grate is secured to channel body with four-point snap-in locking system

Literature & Resources

NDS Drainage Product Catalog 2024-2025

Catalogue

NDS Drainage Product Catalog 2024-2025

Guía de diseño y instalación de drenaje

Reference (NDS)

Guía de diseño y instalación de drenaje

NDS BG-FILCOTEN® Trench Drains & Grates Written Spec

CSI Specifications

NDS BG-FILCOTEN® Trench Drains & Grates Written Spec
