BG-FILCOTEN® pro V 200 Trench Drain with Galvanized Steel Rails, 11.22 in. to 11.42 in. Invert Depth, 8.74 in. Wide X 39.37 in. Long X 12.40 in. Deep, Sloped Channel 10

SKU:

10620210

The female interlocking end of the constant depth channel 5-0 BG-FILCOTEN® by NDS® pro V 200 Trench Channel Drain with Galvanized Steel Rails, an 8 in. wide trench drain with high-load capacity made of high-performance concrete (HPC)

The 8 in. wide BG-FILCOTEN® by NDS® pro V 200 Trench Channel Drain with Galvanized Steel Rails comes in multiple channel depths in both constant depth and sloped channel sections (NDS 10620200)

Closeup view of the male interlocking end of the BG-FILCOTEN® by NDS® pro V 200 Trench Channel Drain with Galvanized Steel Rails

The BG-FILCOTEN® high-performance concrete trench drain is a modular drainage system that consists of constant depth and sloped channel sections. The pro V 200 series features 8 in. wide channels with galvanized steel rails. Channel 10 is a sloped section with an invert depth from 11.22 in. to 11.42 in. BG-FILCOTEN drains stand apart from concrete channel drains due to its unique engineering and materials. This powerful trench drain has all the features of a stable concrete channel, yet constructed with high-performance concrete for sheer strength and durability. Built for high-load capacity, it is ideal for commercial, industrial, and municipal applications.

Where to Buy Find a Contractor

Applications

Captures surface runoff and conveys to connected drain pipe to prevent costly property damage and mildew growth which can lead to slip hazards and concrete staining
Ideal for factories, warehouses, garages, railway stations, municipal areas, and areas with similar surfaces
As part of a complete drainage system, the BG-FILCOTEN® trench drain works with drain grates to capture stormwater runoff and convey it to drain pipe for proper release downstream

Features

Made of high-performance concrete (HPC), the channel is lighter than most conventional concrete channels for lower transport costs, easier handling, and faster installation
Handles high-load capacity; load rating based on type of grate installed
Anchoring ribs support the channel and increase the surface area for better adhesion to surrounding concrete
